iEM-RS2313
Product Category

iEM-RS2313

● NEMA23, 1.3N.m

● Low noise and vibration, smooth motion

● Support Modbus RTU protocol, Internal 16-segment position commands

● Motion can be started by external I/O or RS485 or HMI

● Support operation modes: Profile Position, Profile Velocity, Homing

● 7 configurable digital inputs, 3 optically isolated digital outputs

● RS232 port for tuning software connection, RS485 port for motion control

● Over voltage, over current, etc. protections



List Price: $ 199.00
Online Special Price: $ 199.00

iEM-RS Series is an integrated stepper motor integrated drive, and based on standard Modbus RTU protocol, using RS485 communication can network up to 31 axes. Its built-in PR feature with 16-segment position table (PR Mode) can save additional controllers in most of point-to-point applications, to greatly enhance system reliability and reduce the cost.

The iEM-RS series motors are highly reliable and affordable and performs excellently in many industrial applications such as solar equipment, textile, civil, robotics, power generation equipment, 3C, packaging...

Technical Data
ModeliEM-RS2313
SeriesiEM-RS
Frame Size (NEMA)NEMA23
Length (mm)78
Holding Torque (N.m)1.3
Command SourceModbus-RTU
Operation Voltage (VDC)24, 36
Input Frequency (KHz, Max.)10
Logical Voltage (VDC)12 -24
# of Inputs3
# of Outputs1


Mechanical
