2EM3E-522
Product Category

2EM3E-522

  • Dual-axis control via one IP address, support CiA402

  • EtherCAT communication

  • Support operation modes: PP, PV, HM, CSP

  • 2*4 digital inputs, 2*2 optically isolated digital outputs include alarm and brake

  • Low noise and vibration, smooth motion

  • 20-50VDC supply voltage, max 2.2A output current

  • Over voltage, over current, motor cable error protection, etc

  • STO optional

List Price: $ 199.00
Online Special Price: $ 199.00

2EM3E series drives support operating modes: PP, PV, HM, CSP. The products can be matched with most of master station such as Beckhoff, Omron, Keyence, Panasonic etc.

Technical Data
Model2EM3E-522
Series2EM3E
Command   SourceEtherCAT
Operation   Voltage (VDC)20-50
Output   Current (A, Peak)2.2
Input   Frequency (KHz, Max.)10
Logical   Voltage (VDC)12-24
# of Inputs2*4
# of Outputs2*2
CharacteristicsStandard
