No loss of step, no hunting, no torque reservation.
Dual-axis control via one IP address, support CiA402
EtherNet/IP communication
Support operation modes: Profile Position, Profile Velocity, Homing
2*4 configurable digital inputs, 2*2 optically isolated digital outputs include brake output
Low noise and vibration, smooth motion.
USB port for Leadshine software connection.
Two 7-segment display velocity or slave ID or operation mode or error code.
Over voltage, over current and position following error, encoder cable error, etc. protections
STO optional
2CS3EIP series drives support operating modes: Profile Position (PP), Profile Velocity (PV), and Homing (HM). The products can be matched with most of master station such as Beckhoff, Omron, Keyence, Panasonic etc.
